Low Cost Plastic Injection Molding Machine SK80

Product Review | Top Rated

  • Color: Default Color
  • Size: Default Size
  • Port: China
  • Lead Time: Default Usage
  • Packaging: Default Type
  • MOQ: 99.9% Type

Description:

Essential details
Plastic Processed:
PP, PC, ABS, PET, PVC, FRPP/PVC, PPR, EVA, HDPE, MLLDPE, EPS, PA, Polystyrene, PE, LDPE, EVOH, HDPE/PP, ABS/PP, PE/PP
Condition:
New
Style:
Horizontal
Distance between Tie Bars(Width)(mm):
370mm
Distance between Tie Bars(Height)(mm):
370mm
Ejector Stroke(mm):
100 mm
Ejector Force(kN):
31 kN
Theoretical Shot Volume(cm³):
157 cm³
Injection Rate (g/s):
83 g/s
Machine Type:
Hybrid
Injection Weight (g):
126 g
Screw Speed (rpm):
1 - 205 rpm
Screw diameter (mm):
36 mm
Screw L/D Ratio:
21
Distance between Tie Bars:
370X370
Weight (KG):
3000
Type:
Tube Shoulder Injection
Place of Origin:
Zhejiang, China
Open Stroke(mm):
335 mm
Model Number:
SK80
Brand Name:
TURN
Power (kW):
17.6 kW
Warranty:
1 Year
Key Selling Points:
Sustainable
Applicable Industries:
Hotels, Garment Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Advertising Company
Showroom Location:
Argentina, Chile, Colombia, Sri Lanka, Uzbekistan
Machinery Test Report:
Not Available
Video outgoing-inspection:
Provided
Warranty of core components:
1 Year
Core Components:
Bearing, Motor, Pump, Gear, PLC, Screw
Clamping Force (kN):
800 kN
After-sales Service Provided:
Video technical support, Free spare parts, Field installation, commissioning and training, Field maintenance and repair service, Online support
After Warranty Service:
Online support, Spare parts, Field maintenance and repair service
Local Service Location:
Viet Nam, Brazil, Pakistan, Mexico, Argentina, Chile, Colombia, Sri Lanka, Bangladesh, Uzbekistan
Marketing Type:
New Product 2020
Packaging & delivery
Port
Ningbo
Lead time:
Quantity(sets) 1 - 10 >10
Lead time (days) 15 To be negotiated
Video Description

00:00

00:16
Product Description
Why us
High  performance value ratio
Our 80T machines are cheaper 30% than normal machines but quality is good.
Customer Photos
Contact us

Turn Machine

Core Offerings

Turn Machine (Zhejiang) Co., Ltd
Injection Molding Machine

Our advanced injection molding machines are designed for high-precision manufacturing, ensuring consistent quality and efficiency in plastic production.

Clamping System

We provide robust clamping systems that securely hold molds in place during the injection process, enhancing the accuracy and durability of the final product.

Stable Injection Device

Our stable injection devices deliver precise and controlled plastic flow, minimizing defects and optimizing the production process.

Hydraulic Unit

The hydraulic units we offer ensure smooth and powerful operation of the molding machines, contributing to reliable and efficient production cycles.

Electric Unit

The hydraulic units we offer ensure smooth and powerful operation of the molding machines, contributing to reliable and efficient production cycles.
